Foam Pigs for Pipelines

One of the foam pigs for pipelines is a spiral wire brush Polly pig. So, it consists of foam rubber into a conical head of the cylinder. Then, after adding other auxiliary equipment on its surface. Such as spiral wire, installation of a variety of wear-resistant rigid wire brush materials. It is mainly used for cleaning and rust removal on the inner wall of pipes. It is really excellent for cleaning and rust removal of pipes.

Category:

Description

LCQZ-RTB Foam Pigs for Pipelines

Starting pressure: 0.03 MPa
Density: 35 kg/m³~200 kg/m³
Withstand pressure: 7 MPa
Stretch rate: 320%
Compression ratio: 40
Flex life: 50,000 times
Attrition rate: 2 mm/100 km
Operating distance: 50 km~150 km
Operating temperature: -30℃~100℃

Name

EMT Foam Pigs for Pipelines

Material

Polyurethane

Light density – 0.02-0.03g/cm3

Medium density –0.08-0.12g / cm3

Heavy density – 0.13-0.16g/ cm3

Feature

1.     high wear resistance.

2.     Good cleaning performance.

3.     low-cost.

Packing way

Packed foam pigs with inner plastic film and outer plywood wooden case.

Payment

TT/LC

Advantage

1. They are lightweight and flexible.

2. Nice cleaning efficiency.

3. Accurate location tracking.

Shenyang EMT Pipng Technology CO. LTD is a manufacturer of pipe cleaners, skeleton cleaners, full-polyurethane foam pigs, foam cleaners, pig passage indicators for pipelines, corrosion coupons, corrosion probes, chemical injectors, pig launchers and receivers, quick opening closures, and other products. The cleaning technology of foam pigs for pipelines produced by Shenyang EMT. Therefore, the company has unique characteristics compared with other types of cleaning pigs. It is suitable for all kinds of lengths of pipes and pipes of different diameters and sizes. With suitable accessories, it can easily clean the hard scale and impurities in the pipes that are difficult to clean. Foam ball pipe cleaner features: better passability, lower cost, shorter cleaning time, and easier to use. Applicable to a variety of pipelines.



Brush Foam Pigs for PipelinesWire Brush  Pig

One of the foam pigs for pipelines is a spiral wire brush Polly pig. So, it consists of foam rubber into a conical head of the cylinder. Then, after adding other auxiliary equipment on its surface. Such as spiral wire, installation of a variety of wear-resistant rigid wire brush materials. It is mainly used for cleaning and rust removal on the inner wall of pipes. It is really excellent for cleaning and rust removal of pipes.

The features are softer materials, better flexibility, and easier to pass the pipe with more curves. The product is mainly used in the interior of the pipe to remove water, oil, and dry. We can scrub, and remove impurities such as scale and corrosion products in the pipeline. And we are able to use it for pipeline detection by using foam pigs. The advantages of foam pigs for pipelines is simpler processing, relatively lower price, and better water absorption performance.

The tool can remove the oil scale, and rust. Moreover, the inner wall of the pipe, will not cause any damage to the pipe instead of removing the scale on the wall of the pipe. This is a common material to use in pipe cleaning. Stainless steel brushes in the use of some problems may solve these questions.  We need to make some improvements to the carbide brush. The purpose is to use it more conveniently and safely.

Polyurethane specification:

NO.Factory inspection main indicatorsCup/DISC
120℃Hardness(SHORE  A) 85±2
2Tensile strength (MPa)51.7
3100%stress at definite elongation (MPa)4.8
4300%stress at definite elongation (MPa)9.2
5Tensile set (%)780
6Tear strength (KN/m)73.0
7Impact resilience (%) 32
8DIN abrasion (mm²)35
